1. Filter Area: For example, *0 square meters, **0 square meters,
etc. It determines the flow rate of gas that the dust collector
can handle. The larger the filter area, the greater the amount of
dust - laden gas that can be processed per unit of time.
2. Filter Air Velocity: Generally between 0.6 - 1.2 meters per
minute. It reflects the speed at which the dust - laden gas
passes through the filter bag. If the air velocity is too high,
it will affect the dust collection efficiency and the service
life of the filter bag. If the air velocity is low, the size of
the equipment may be relatively large.
3. Filter Bag Material: Common ones include polyester needle -
punched felt and aramid needle - punched felt. Polyester needle -
punched felt has good acid and alkali resistance and a relatively
low cost. Aramid needle - punched felt has outstanding high -
temperature resistance and flame - retardant properties, making
it suitable for high - temperature environments.
II. Performance Parameters
1. Processing Air Volume: For example, ***0 cubic meters per
hour, ***0 cubic meters per hour. It refers to the volume of dust
- laden gas that the dust collector can handle per unit of time
and is an important indicator for measuring the processing
capacity of the dust collector.
2. Dust Collection Efficiency: Generally, it can reach over *9%.
It represents the ability of the dust collector to capture dust.
The higher this value, the lower the dust content in the
discharged gas.
3. Resistance: Usually between ***0 - ***0 Pascals. The magnitude
of resistance reflects the pressure loss that the gas experiences
when passing through the dust collector. Excessive resistance
will increase the energy consumption of the fan.
III. Structural Parameters
1. Overall Dimensions: For example, length × width × height is 3
meters × 2 meters × 4 meters, which affects the installation
space requirements of the equipment.
2. Number of Filter Bags: Such as *0 pieces, *0 pieces, etc. The
number of filter bags is related to the filter area and also
affects the design and operation of the ash cleaning system.
3. Ash Hopper Volume: For example, 2 cubic meters, 3 cubic
meters. It is used to store the collected dust. The size of the
volume needs to be determined according to the dust generation
amount and the ash cleaning cycle.
| 国: |
China |
| モデル番号: |
EC-120
|
| 离岸价格: |
200 ~ 660 / Unit ( Negotiable ) （交渉可能）
Get Latest Price
|
| ロケーション: |
CHINA |
| 最低注文量の価格: |
200 per Unit |
| 最低注文量: |
200 Unit |
| パッケージの詳細: |
Packed in cartons lined with waterproof plastic bags |
| 納期: |
15 to 20 days |
| 供給能力: |
1000 Unit per Month |
| 支払いタイプ: |
T/T, L/C |
| 製品グループ : |
- |
