1800C U shape MoSi2 heating element for high temperature Furnace By HENAN VINER INDUSTRIAL CO., LTD.,

製品仕様

Diameter:3/6, 4/9, 6/12, 9/18, 12/24mm
Heating temperature:1700-1900C
Type:U, W, L, etc

タイトルまたは説明

1800C U shapeMoSi2 heating elementfor high temperature Furnace

VINER Industrial Molybdenum Disilicide MoSi2 heating element is a resistance generate-heating component made from MoSi2 or the basic material. It is used in high temperature under the oxidizing atmosphere, it looks like glass in its surface and form a light SiO2 glass film which can protect the element not to be oxidized. So this kind of element has unique effect for resisting oxidization in the high temperature. It is used to the highest temperature up to 1800C during oxidizing atmosphere. According to your request, our company can produce the products of Pole, "U", "W" and "U"-right angle shapes, etc.

VINER Industrial MoSi2 heating element can usually make use of furnace temperature from 1300C to 1900C. It is extensively used in the industries of metallurgy, glass, ceramic refractory, crystal electronic device, industrial furnace manufacture, etc. It is an essential ideal element when the products are sintering in the high temperature.

VINER Industrial Mosi2 Heating elements Physics and Chemistry Characters:

1. Physics Characters

Volume Density	Bending Strength	Vickers Hardness	Porosity	Water absorption	Heating Elongation Rate
5.5 g/cm3	15-25 kg/cm3	(HV)570kg/mm2	7.4%	1.2%	4%

2. Chemistry Character
VINER Industrial MoSi2 heating elements are used in the high temperature under oxidizing atmosphere. It will form the SiO2 film which can keep the element from being melted. During the oxidizing process, the SiO2 protecting film is formed again when the element continues to be used. The MoSi2 heating element must not be used in the temperature between 400C and 700C for a long time, otherwise the element will be cremated under the strong oxidizing function in the low temperature.

Now, VINER Industrial supply 3 types U shape MoSi2 Heating elements, one is 1700 type, which ensure max. furnace temperature 1650C; one is 1800 type, which ensure max. furnace temperature 1700C; another one is 1900 type, which ensure max. furnace temperature 1800C. When you place order, please choose suitable type according to your furnace working temperature.
1700 (heat furnace temperature 1650C)
1800 (heat furnace temperature 1700C)
1900 (heat furnace temperature 1800C)

When you place an order of the VINER Insutrial U Shape Mosi2 Heating elements, please give following information:
Material Grade: 1700/1800/1900
C: Hot Zone Diameter
D: Cold Zone Diameter
Lu: Cold Zone Length
Le: Hot Zone Length
A: Shank Spacing

Order Sample of the VINER Indutrial U Shape Mosi2 Heating elements
U Shape: Material Grade: 1800, c=3mm, d=6mm, Le=140mm, LU=125mm, A=25mm
Specify As:3/6×140×125×25

VINER Insutrial MoSi2 Heating element's Installation:
The brittleness of MoSi2 heating element is relative more under the usual temperature, it also has plasticity under the high temperature. So you had better hang and erect vertically the "U"-shape element. If you need to erect it horizontally, please choose a support of high-temperature insulating materials. The cone-part of the element must extend inside the furnace. At first the fixture of MoSi2 power connector cant be screwed too tightly. When temperature of the element is going up, please twist it tightly again, so the element is not easily broken.(our suggestion: please choose the specialize power connector provided by our company)

The furnace top must be a good function of heat-preservation. In general, the temperature of furnace top cant be over 300C. The voltage should be low 0.1 between the power connector and the element. In order to avoid radiating heat to pass the connector, the distance is not less than 50mm between the low end of connector and the upside of the ceramic brick. The Dia.6 element cant be used of 170A for a long time. The Dia.9 element cant be used of 300A for a long time.

Notice to Furnace Operation:
To avoid high current surges which may cause damage to MoSi2 heating elements, the recommend starting procedure as following:

Small Furnace (Power 100kw)		Big Furnace (Power 100kw-500kw)
Furnace Temperature .C	Voltage	Furnace Temperature .C	Voltage
20-150	1/3	20-300	1/3
150-500	2/3	300-700	2/3
500-Working Temperature	Full	700-working Temperature	Full
Note:Shifting gear must be done quickly, otherwise high current surges may cause damage.

VINER Industrial U Shape Mosi2 Heating element Packaging:
In Standard Wooden Case, VINER Industrial could be lifting packing.

VINER Industrial U Shape Mosi2 Heating element Shipment:
VINER Industrial could supply you the follow shipping way for your choice:
--By DHL/Fedex (Door to door, Home delivery service)
--By Air to your nearest Airport
--By Sea to your nearest Seaport
--By the sellers shipping agent

According to your request, our company can produce the products of MoSi2 heating elements, "U", "W" and "U"-right angle shapes, etc.

Welcome to visit manufacture line!! Wait for your testing our high temperature MoSi2 heating elements!!

Company Information
VINER Industrial specializes in MoSi2 heating elements 1700, 1800, 1900, have U, W, L and Special shape several types with diameter 3/6, 4/9, 6/12/, 9/18, 12/24mm. SiC heating elements with ED (Rod, Straight) type, U type, W type, L type, Slot type, Single Spiral, Double Spiral, UX type and diameter 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm, 30mm, 31.7mm (1.25inch), 35mm, 38.1mm (1.5 inch), 40mm, 44.4mm (1.75 inch) to 54mm (2.125 inch), 75mm (2.95 inch).

Also different sizes and kinds of high temperature furnaces including Muffle Furnace, Vacuum Tube furnace, Vertical Tube Furnace, Rotary Tube furnace, Vacuum Crucible furnace, Vacuum Box furnace, Atmosphere Furnace, Bottom Loading furnace, and Vacuum Drying Oven, the chamber sizes could be according to customers' design. What is more,VINER Industrialproduces and supplies high temperature Kiln Furnace Spare Parts including MoSi2/SiC/Resistance Wire heating elements, Ceramic Fiber Insulation, Alumina/Zirconia Ceramics, Silicon Carbide Ceramics, Boron Nitride (BN) Ceramics, Vacuum Flanges, Thermocouple, PID Temperature Controller, and Quartz Furnace Tube. Ps kindly inquiry us, we will try our best to serve you.

Welcome to visit manufacture line!!

Guaranteed Quality:Our MoSi2/SiC heating elements are warranted to be free from defects in materials or workmanship for 1 years from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.

Sound after Sales Service:We provide sound after sales service. We provide 24 hours consultation service. We are ready to answer your consultations at any time.

Our Services
1. Your inquiry related to our products or prices will be replied within 24hours
2. Guarantee samples quality same as mass production quality
3. All our products have 2-years warranties.
4. Offering the support to solve the problem in the application or selling period.
5. Competitive prices based on same quality

FAQ
1. Can you accept OEM?
Yes! We can manufacture as per your request size.
2. Can you deliver the goods via our shipping agent?
Yes, we could help you make the delivery using your shipping agent
3. Can you supply sample:
We could like to give you suitable suggestion about the SiC heating elements according to your detail application.
4. What about your After-sales service:
We promise that we can change or refund products if there are any quality problem.

国:	China
モデル番号:	VN-MS1800-U01
离岸价格:	3.2 ~ 22.26 / Piece ( Negotiable ) （交渉可能） Get Latest Price
ロケーション:	China
最低注文量の価格:	3.2 per Piece
最低注文量:	2 Piece
パッケージの詳細:	In exporting wooden case
納期:	3-5days
供給能力:	30000 Piece per Month
支払いタイプ:	PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T
製品グループ :	MoSi2 heating element
