FOB Price
Get Latest Price4700 ~ 23000 / Set ( Negotiable )
|Minimum Order
Place of Origin:
-
Price for Minimum Order:
Minimum Order Quantity:
1
Packaging Detail:
wood case
Delivery Time:
5-10days
Supplying Ability:
1 Set per Year
Payment Type:
T/T, L/C, D/A, D/P
連絡先担当者 Amy
Chongqing, Chongqing
Applicable
scope:
It is widely suitable for
online processing of steam turbine, the gas turbine, the
hydraulic turbine's oil in electric power, chemical industry, papermaking,
metallurgy and so on to guarantee the unit adjusting and the
normal work of the lubrication
system.It used physical method
remove the water,
impurities and gas(acetylene, hydrogen, methane, etc), it
will not change the oil
components and performance.
Accessories:
Item | unit | ZJC-10 | ZJC-20 | ZJC-30 | ZJC-50 | ZJC-75 | ZJC-100 | ZJC-150 | ZJC-200 | ||
Flow rate | L/H | 600 | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 | ||
Vacuum degree | Mpa | -0.06 ~ -0.096 | |||||||||
Working pressure | Mpa | ≤0.3 | |||||||||
Fault free | H | ≥4000 | |||||||||
Continuous working time | H | ≥150 | |||||||||
Working temperature | °C | 40 ~ 70 | |||||||||
Heating power | kW | 15 | 18 | 30 | 45 | 60 | 72 | 72 | 84 | ||
Total Power | kW | 17 | 20 | 33 | 49 | 66 | 79 | 81 | 97 | ||
Oil index after treatment | |||||||||||
Water content | 80ppm | ||||||||||
Gas content | ≤0.1% | ||||||||||
cleanness | ≤5µm(or as per requirement) | ||||||||||
Demulsification Value | ≤10 min |
Technical specification
