LED Flexible Transparent Film Display

离岸价格

Get Latest Price

100 ~ 1000 USD / Square Meter

1 Square Meter Minimum Order

国:

China

モデル番号:

P2.34-3.47 P2.6-5.2 P5.2-10.4 P3.125-3.125 P3.91-7.81 P7.81-7.81 P10.4-10.4 P20-20

离岸价格:

100 ~ 1000 USD / Square Meter （交渉可能） Get Latest Price

ロケーション:

China

最低注文量の価格:

100 per Square Meter

最低注文量:

1 Square Meter

パッケージの詳細:

Box

納期:

15-30

供給能力:

10000 Square Meter per Month

支払いタイプ:

T/T

製品グループ :

LED Display Screen

今すぐお問い合わせください

Exinmind

China

3000 信任点

1st 年

連絡先担当者 Spring

Shenzhen, Guangdong

今すぐお問い合わせください

製品仕様

タイトルまたは説明

Easy Installation

No steel structure required,just simply stick the LED film to

existing sufaces and connect the power signal.

Self-developed glue filling process(The screen film comes

with its own viscosity that can be directly attached to the glass

surface, and the colloid has strong adsorption force. Due to the

inherent characteristics of the colloid itself, the viscosity will also

increase over time.)

High Transmittance

Ultra -high transparency, the transmittance are more than 90%.

Flexible

Suitable for any surface

Model	P5	P6.25		P8		P10		P15	P20
Module Size (mm)	320*1000	400*1000		400*1000		400*1000		390*990	1000*400
LED Light	1313	1313	2121	1313	2121	1313	2121	2121	2121
Brightness cd/m²	2500	2000	4000	2000	4000	2000	4000	2000/4000	2000/4000
PixelComposition	R1G1B1	R1G1B1		R1G1B1		R1G1B1		R1G1B1	R1G1B1
Pixel Spacing(mm))	5*5	6.25*6.25		8*8		10*10		15*15	20*20
Module Pixel	200*64=12800	160*64=10240		125*50=6250		100*40=4000		66*26=1716	50*20=1000
Pixel/m²	40000	25600		15625		10000		4356	2500
Permeability	90%	92%		92%		94%		94%	95%
Angle of View°	160	160		160		160		160	160
Input Voltage	AC100-240V50/60Hz	AC100-240V50/60Hz		AC100-240V50/60Hz		AC100-240V50/60Hz		AC100-240V50/60Hz	AC100-240V50/60Hz
Peak Power	600w/m²	600w/m²		600w/m²		600w/m²		600w/m²	600w/m²
Average Power	200w/m²	200w/m²		200w/m²		200w/m²		200w/m²	200w/m²
Work Environment	Temperature-20~55â„ƒ Humidity10-90%	Temperature-20~55â„ƒ Humidity10-90%		Temperature-20~55â„ƒ Humidity10-90%		Temperature-20~55â„ƒ Humidity10-90%		Temperature-20~55â„ƒ Humidity10-90%	Temperature-20~55â„ƒ Humidity10-90%
Weight	1.3kg	1.3kg		1.3kg		1.3kg		1.3kg	1.3kg
Thickness	2.0mm	2.0mm		2.0mm		2.0mm		2.0mm	2.0mm
Drive Mode	Static State	Static State		Static State		Static State		Static State	Static State
Control System	Nova/Colorlight	Nova/Colorlight		Nova/Colorlight		Nova/Colorlight		Nova/Colorlight	Nova/Colorlight
Typical Value of Life	100000H	100000H		100000H		100000H		100000H	100000H
Grayscale Level	16bit	16bit		16bit		16bit		16bit	16bit
Refresh Rate	3840 Hz	3840 Hz		3840 Hz		3840 Hz		3840 Hz	3840 Hz

国:	China
モデル番号:	P2.34-3.47 P2.6-5.2 P5.2-10.4 P3.125-3.125 P3.91-7.81 P7.81-7.81 P10.4-10.4 P20-20
离岸价格:	100 ~ 1000 / Square Meter （交渉可能） Get Latest Price
ロケーション:	China
最低注文量の価格:	100 per Square Meter
最低注文量:	1 Square Meter
パッケージの詳細:	Box
納期:	15-30
供給能力:	10000 Square Meter per Month
支払いタイプ:	T/T
製品グループ :	LED Display Screen
