Product Introduction
To solve the problems which Outdoor regular LED display can't
achieve, Outdoor transparent LED display are invented to create
waterproof, transparent, lightweight and thin cabinet which will
be widely used in Conventional glass windows.
The transmittance can reach 60%, without affecting indoor
lighting or the original design; Precision aluminum box with good
natural heat dissipation
Lamp bead sealant and power box sealing treatment ensure good waterproof performance
Seamless connection error＜0.05mm
| Model | P3.91-7.81 | P7.81-7.81 | P10.416-10.416 |
| Pixel pitch(mm) | 3.91-7.81 | 7.81-7.81 | 10.416-10.416 |
| Pixel density(dots/m²) | 32,768 | 16,384 | 9,216 |
| Permeability(%) | 49% | 49% | 58% |
| LED type | SMD1921 | SMD1921 | SMD2727 |
| Module size(mm) | 500x125 | 500x125 | 500x125 |
| Module resolution(dots) | 128x16 | 64x16 | 48x12 |
| Brightness(cd/m²) | 3000-5000 | 3000-5000 | 5,000 |
| Avg power consumption(W/m²) | 450 | 450 | 400 |
| Max power consumption(W/m²) | 1000 | 1000 | 800 |
| Scan mode | 1/8 | 1/8 | 1/2 |
| Gray scale(bit) | 16 | 16 | 16 |
| Size(mm) | 1000x500 | 1000x500 | 1000x500 |
| Weight(kg) | 9.0 | 9 | 9 |
| Cabinet material | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
| Refresh rate(Hz) | 1920-3840 | 1920-3840 | 3840 |
| Cabinet color | Black/white | ||
| Working environment | Outdoor | ||
