UL 2808 Clamp On Current Transformer 150A 0.333V

离岸价格

Get Latest Price

10 ~ 18 USD / Piece ( Negotiable )

|

1 Piece Minimum Order

国:

China

モデル番号:

XH-SCT-T24-200

离岸价格:

10 ~ 18 USD / Piece ( Negotiable ) Get Latest Price

ロケーション:

China

最低注文量の価格:

10 per Piece

最低注文量:

1 Piece

パッケージの詳細:

Cartons

納期:

7-15 days

供給能力:

60000 Piece per Month

支払いタイプ:

T/T

製品グループ :

split core CT/current transformer

今すぐお問い合わせください
Jiangyin Xinghuo Deyue Technology Co., Ltd

Jiangyin Xinghuo Deyue Technology Co., Ltd

China

8888 信任点
1st 年

連絡先担当者 Mr. Jay

No.68, Tian'an Cyberpark, No.55 Changshan Avenue, Jiangyin, Wuxi, Jiangsu

今すぐお問い合わせください

製品仕様

  • Material:Stainless Steel
  • Accuracy Grade:0.5G
  • IP Rating:IP20
  • Certification:CE, UL, ROHS, ISO9001: 2008
  • HS Code:8504

タイトルまたは説明

XH-SCT-S24 Split Core Current Transformer Clamp CTs 200A 0.33V

SPECIFICATIONS:
1,Rated Voltage:0.66KV
2,Insulation Voltage:5KV
3,Rated Frequency:50HZ or 60HZ
4,Operating Temperature:-15ºC to 60ºC
5,Flame resistance:UL94-V0
6,Certificates:CE,UL2808
Model Input(A) Max current(A) Output
XH-SCT-S24 0.2-250AAC 300AAC mA/0.333VAC/0-5VAC

Accuracy (1% - 100% of rated current) ±0.5 %
CT Phase Angle (5% - 120% of rated current) 0.5 (Ultracrystalline)  / 1.5± 0.5(Silicon iron) Degrees
Nominal Line Frequency 60 / 50 Hz
Current Rating 225 A
Output Voltage 0 - 333 mVac
Overvoltage AC 5000V/0.3mA/60S  (50HZ/60HZ) Vac
Maximum Continuous Amps 300 A
MECHANICAL
Type Split core, clamp design
Average Window Diameter 24 mm

Lead Wire 		Type Twisted pair MTW,UL105
  Length 17 / 5.2 ft/m
  Gauge 20 AWG
Weight 190  g
ENVIRONMENTAL
Operating Temperature Range  -40 to 60 °C
Operating Humidity 5% to 90% relative humidity
IP Rating 30 (NEMA 1)



Performance:

Shipment

Hot Sales


国: China
モデル番号: XH-SCT-T24-200
离岸价格: 10 ~ 18 / Piece ( Negotiable ) Get Latest Price
ロケーション: China
最低注文量の価格: 10 per Piece
最低注文量: 1 Piece
パッケージの詳細: Cartons
納期: 7-15 days
供給能力: 60000 Piece per Month
支払いタイプ: T/T
製品グループ : split core CT/current transformer
